HELP FILE

Aastra 6751i

Quickstart

Learn how to do the most common functions on your phone.

For a more in-depth look at your phone, please see the manufacturer's user's manual.

Call Forwarding

Automatically forward incoming calls to an internal extension or external number.

  1. Press .
  2. Select Options > Call Forward.
  3. Scroll to the desired mode and select Change.
    • All: Forwards all incoming calls.
    • No Answer: Forwards all unanswered incoming calls.
    • Busy: Forwards calls that arrive when you're already in a call.
  4. Scroll down and press the same key to change the state to On.
  5. Press the back arrow and then # to confirm.
  6. Scroll down and select Number.
  7. Enter the internal extension or external number to which calls will be forwarded.
  8. If you selected No Answer, enter how many rings to wait before forwarding.
  9. Press the back arrow and then press # to confirm.
To disable call forwarding, turn Off the call forward mode.

Do Not Disturb (DND)

Stop your phone from ringing and send all incoming calls directly to voicemail.

Calls are not logged in your missed calls.
  1. Press .
  2. Highlight DND and use the right arrow key to enable/disable.

Voicemail Access

Check your voicemail from your phone.

  1. Dial *99.
  2. Dial your password (default 0000).

    Download your Voicemail Menu Guide.

Speed Dial

Assign regularly dialed numbers to additional line keys on your phone.

The amount of available speed dial keys are setup by a system admin from the Web UI.
  1. Press .
  2. Select Preferences > Speed Dial Edit.
  3. Press the speed dial key you wish to edit.
  4. Edit the contact information.
  5. Press the right arrow key to save your changes.

3-Way Calls

Speak with two parties simultaneously by creating a mini-conference call on your line.

  1. While on an active call, press .
  2. Dial the internal extension or external number to add to the conference.
  3. Wait for the second party to answer, and then let them know that you would like to add them to a 3-way call.
  4. Press again.

Warm Transfer

Place a current call on hold and speak with the destination party before transferring the call.

  1. While on an active call, press .
  2. Dial the internal extension or external number.
  3. Speak with the destination party.
  4. Press again.

Blind Transfer

Transfer a call to another party without speaking to them first.

  1. While on an active call, press .
  2. Dial the internal extension or external number.
  3. Press before the destination party answers.

    To transfer a call directly to voicemail, dial 0 + extension.

Hold

Place a call on hold while you take some time to look up an answer to a question or answer another call.

  1. Press .
  2. Press to retrieve the call.

Modify Ringtone

Choose a new ringtone for your phone or assign a different ringtone to each of your lines.

  1. Press .
  2. Select Preferences > Tones > Ring Tones.
  3. Select the desired ringtone (highlight to sample ringtones).
  4. Press the Set/Done softkey.

    This device supports silent ringtones.

Presence Monitoring

Visually monitor the speed dial contacts assigned to your phone to know whether or not they are on an active call. These line keys will light up (busy lamp field) indicating if someone is busy or available.

This device does not support this feature.

Supported Features

Call Handling Features

  • Warm Transfer
  • Blind Transfer
  • Do Not Disturb (DND)
  • Call Forward All
  • Call Forward Busy
  • Call Forward No Answer
  • Intercom (* + ext)
  • Hold
  • Reject
  • Multi-way Calling
  • Call Waiting
  • On Hook Dialing
  • Speakerphone
  • Stutter Tone

User Interface Features

  • Adjustable Ringer Volume
  • Call Logs
  • On Device Directory

Feature Keys

  • 1 SIP Account
  • On Device Speed Dial Edit

Display

  • Black & White Display
  • Message Waiting Indicator (MWI)
  • Caller ID (CID)
  • Time/Date Display (does not support Arizona Timezone)
  • On Screen Message Display

Network & Provisioning

  • Cisco Multicast
  • Web Interface Provisionable
  • PC Connection
  • Web Interface Provisionable

Hardware

  • Wired Headset

Provisioning

  1. Verify you have created a device profile.
  2. Verify you have assigned the phone's MAC address to the device profile.
  3. Verify you have properly plugged in the phone.
  1. Press .
  2. Select Options > Admin Menu.
  3. Enter the password 22222.

    If this password is not accepted, contact Customer Support for assistance.

  4. Select Network Settings and then write down the phone's IP Address.
  5. Open an incognito window in Google Chrome, enter the IP address in the address (URL) bar and then press enter on your keyboard. If the web UI doesn't load, enter https:// before the phone’s IP address.
  6. Log in as an Admin with the password 22222.

    If this password is not accepted, contact Customer Support for assistance.

  7. Go to Configuration Server and define the following settings:
    Option Description
    Download Protocol HTTP
    HTTP Server ‹domain›.onjive.com
    Replace ‹domain› with your unique domain (found in parentheses at the top of the admin portal dashboard).
    HTTP Path ‹domain›/p
    Replace ‹domain› with your unique domain (found in parentheses at the top of the admin portal dashboard).
    Mode Both
  8. Select Save Settings > Reset > Restart.
If the phone doesn’t automatically reboot, power cycle the device to apply its provisioning settings.

Reset Secure Provisioning

After you factory reset a phone, you’ll need to reset secure provisioning from the admin portal so it can reconnect.

  1. Log in at https://my.jive.com/pbx.
  2. Click Devices in the left sidebar and then choose the device that needs secure provisioning reset.
  3. From Hardware > Reset Secure Provisioning, click Reset.
